Home >> Chlorine And Chemical Filtration

TRIONICS Model
Eco-CAT

TRIONICS ECO-CAT (Chloramine/Chlorine/Chemical) Whole House Chemical Filter for Municipal Water

The Trionics ECO-CAT is made with special catalytic carbon. It is a Select coconut shell charcoal manufactured utilizing steam activation. The catalytic activity of this activated carbon makes it highly effective for breaking apart the bonds of Chlorine and Ammonia. Once Chloramine is broken down the catalytic carbon with its large micro pore volume makes it particularly well suited for the removal of chlorine, taste, odor, organic compounds and disinfection by-products (DPB’s) such as chloroform and other trihalomethanes (THMs).

How Does It Work?

Carbon is a substance that has a long history of being used to absorb impurities and is perhaps the most powerful absorbent known to man. One pound of carbon contains a surface area of roughly 125 acres and can absorb literally thousands of different chemicals. Activated carbon is carbon which has a slight electro-positive charge added to it, making it even more attractive to chemicals and impurities. As the water passes over the positively charged carbon surface, the negative ions of the contaminants are drawn to the surface of the carbon granules.

Activated carbon filters used for home water treatment typically contain either granular activated carbon (GAC) or powdered block carbon. The two most important factors affecting the efficiency of activated carbon filtration are the amount of carbon in the unit and the amount of time the contaminant spends in contact with it. The more carbon the better. Similarly, the lower the flow rate of the water, the more time that the contaminants will be in contact with the carbon, and the more absorption that will take place.

All Trionics activated carbon filters use coconut shell carbon. There are two principal mechanisms by which activated carbon removes contaminants from water; adsorption, and catalytic reduction, a process involving the attraction of negatively charged contaminant ions to the positively charged activated carbon.

Organic compounds are removed by adsorption and residual disinfectants such as chlorine and chloramines are removed by catalytic reduction.

ECO-CAT Features

Features
  • Clack WS-1CS BW Valve-Electronic Metered Demand Control
  • Eco-CAT – Catalytic Carbon -NSF/ANSI Standard 61 Certification
  • Down flow filtering for maximum effective removal
  • Media Manufacturer Recommended Sizing for proper contact time and removal of Chloramine/Chlorine at 3 – 4 ppm
  • Excellent odor and taste removal
  • No Regenerates necessary
  • Diagnostic bypass valve
  • Designed for .75 to 3 inch plumbing lines
  • Made in the USA.

TRIONICS MODEL ECO-AC Whole House Chemical Filter/Softener

The Trionics Model ECO-AC filtering system provides quality soft and clean conditioned water at every tap in your home at an affordable price.

The Trionics ECO-AC is made with catalytic coconut shell carbon for superior chloramine-chlorine, taste and odor removal as well as organic compounds and disinfection by-products (DPB’s) such as chloroform and other trihalomethanes (THMs).

How Does It Work?

Carbon is a substance that has a long history of being used to absorb impurities and is perhaps the most powerful absorbent known to man. One pound of carbon contains a surface area of roughly 125 acres and can absorb literally thousands of different chemicals.

Activated carbon is carbon which has a slight electro-positive charge added to it, making it even more attractive to chemicals and impurities. As the water passes over the positively charged carbon surface, the negative ions of the contaminants are drawn to the surface of the carbon granules.

Activated carbon filters used for home water treatment typically contain either granular activated carbon (GAC) or powdered block carbon. The two most important factors affecting the efficiency of activated carbon filtration are the amount of carbon in the unit and the amount of time the contaminant spends in contact with it. The more carbon the better. Similarly, the lower the flow rate of the water, the more time that the contaminants will be in contact with the carbon, and the more absorption that will take place.

All Trionics activated carbon filters use coconut shell carbon. There are two principal mechanisms by which activated carbon removes contaminants from water; adsorption, and catalytic reduction, a process involving the attraction of negatively charged contaminant ions to the positively charged activated carbon. Organic compounds are removed by adsorption and residual disinfectants such as chlorine and chloramines are removed by catalytic reduction.

ECO-AC Features

Features
  • Clack WS-1CS BW Valve-Electronic Metered Demand Control
  • Eco-AC –Catalytic Coconut Shell Carbon
  • Down flow filtering for maximum effective removal
  • Media Manufacturer Recommended Sizing for proper contact time and removal of Chlorine at 3-4ppm.
  • Excellent odor and taste removal
  • No Regenerates necessary
  • Diagnostic bypass valve
  • Designed for .75-to-1.50-inch plumbing lines.
  • Made in the USA.
